ZFIN Image: McCallum et al., 2020, Figure 6


Figure Caption

Figure 6 The <italic>Tg(her4.3:EGFP)</italic> cells are actively proliferating in adult homeostasis.

(A) Adult Tg(her4.3:EGFP) zebrafish flattened intestines immunostained for GFP (green) and the cell-cycle marker MCM5 (red). Actively proliferating GFP⁺MCM5⁺ cells were observed (arrows) throughout the intestine. The majority of the GFP⁺ population remains quiescent (arrowheads). Confocal images are max projections of short confocal stacks. Scale bar: 10 µm in merge panel. (B) Quantification of the percentage of GFP⁺MCM5⁺ cells over the total GFP⁺ population (n = 3). Data are given as mean ± SD.
