ZFIN Image: Lanni et al., 2019, Fig. 6


Figure Caption

Fig. 6 Allelic titration of slc12a7a/kcc4a expressivity revealing necessity and sensitivity to levels of Kcc4a during development. A) Identified deletions in F1 progeny and predicted protein alteration; blue box, sequence targeted by guide RNA. B) Representative pictures of individuals heterozygous for different slc12a7a/kcc4a alleles. C) Barbel phenotypes conferred by different slc12a7a/kcc4a alleles. D) Schematic of Kcc4a protein depicting locations of premature stop codon, 3 amino acid deletion, 6 amino acid deletion (red asterisk), and schleier mutation (yellow asterisk). E) Tabulation of relative length of fins and barbels in F1 progeny heterozygous for each genotype; mean ± SEM is shown. n.s., not significant; *p < 0.05; **p < 0.01 calculated using a one-way ANOVA followed by a Tukey’s multiple comparisons test; n = 6–19 fish per genotype.

Figure Data

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 456(2), Lanni, J.S., Peal, D., Ekstrom, L., Chen, H., Stanclift, C., Bowen, M.E., Mercado, A., Gamba, G., Kahle, K.T., Harris, M.P., Integrated K+ channel and K+Cl- cotransporter function are required for the coordination of size and proportion during development, 164-178, Copyright (2019) with permission from Elsevier. Full text @ Dev. Biol.
