Fig. 3

Expression of vgll4b in zebrafish embryos analyzed by WISH.

Expression of vgll4b at one cell stage (AII), 6 hpf (BII), 12 hpf (CII), 24 hpf (DII-DIV), 36 hpf (EII-EIII), 48 hpf (FII-FVI), 72 hpf (GII-GIII) and 5 dpf (HII). Embryos incubated with vgll4b sense probe are shown as negative controls (AI, BI, CI, DI, EI, FI, GI, HI). Embryos are shown in lateral view with anterior to the left (DI-DIII, EI-FIII, GI-HII), dorsal view with anterior to the top (DIV, FV) or ventral view with anterior to the top (FVI). Box areas in (DII), (EII) and (FII) was shown enlarged in (DIII), (EIII) and (FIII) respectively. Dotted line in (FII) indicates approximate orientation of cross section image showed in (FIV). T, telencephalon; MTc, midbrain tectum; MTg, midbrain tegmentum; HB, hindbrain; LLP, lateral line primordium; P, pharynx; LL, lateral line; Pr, proctodeum; R, retina; L, lens; MHB, midbrain–hindbrain boundary; OfV, olfactory vesicle; OV, otic vesicle; PF, pectoral fin; N, neuromasts; Ep, epidermis; r, rhombomeres; r1, rhombomere 1; PP, pharyngeal pouches; PA, pharyngeal arches; Ed, endoderm; Ve, ventricle; H, heart; PLL, posterior lateral line; ION, infraorbital neuromasts; SON, supraorbital neuromast; OCN, occipital neuromasts; OLN, otic lateral neuromasts; MLN, middle line neuromasts; DTN, dorsal trunk neuromast; SB, swimming bladder.

Figure Data

Expression / Labeling details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 28, Xue, C., Wang, H.H., Zhu, J., Zhou, J., The expression patterns of vestigial like family member 4 genes in zebrafish embryogenesis, 34-41, Copyright (2018) with permission from Elsevier. Full text @ Gene Expr. Patterns
