Figure Caption
Fig. S7
Zebrafish sox5 is expressed in premigratory neural crest similarly to sox10.
(A, C, E) sox5 expression. (B, D, F) sox10 expression. (A-F) 18 hpf. (A, B) Lateral views. (C, D) Dorsal views. (E, F) Transverse sections.
Strong signal of sox5 expression is detected in the head, tail bud, notochord and somites (A, C). A transverse section of the trunk region indicates that sox5 is expressed in the premigratory neural crest cells (E, arrow). (B, D, F) sox10 expression overlaps with sox5 expression in the premigratory neural crest cells (F, arrow).
Scale bar: (A) 200 μm, (E) 20 μm.
