Figure Caption

Fig. 7

In Gα13 morphants, Fn fibrils in the regions in which endocardial and myocardial precursors reside are disrupted. Whole-mount Fn immunostaining was performed in control (A-E, n=6) and gna13a/b MO-injected (A′-E′, n=7) Tg(nkx2.5: ZsYellow/sox17: memCherry) embryos at 13 s (A, A′) Projections of XY views of confocal Z-stacks spanning the left-hand side of the embryo, with labeled myocardial precursors (blue), endoderm (magenta), and Fn fibrils (green). (B, B′) A single Z-plane from Z-stacks in A, A′. (C-E, C′-E′) Images of XZ transverse sections (corresponding colored boxes on the far right corners) of the regions indicated by horizontal pink, yellow and cyan lines in A, A′. Pink dots: presumptive endocardial cell populations; yellow dots: myocardial cell populations; pink arrowheads: leading regions of myocardial populations; yellow arrowheads: regions between endocardial and myocardial precursors; yellow dashed line: midline; D: dorsal; V: ventral. Scale bars: 20 µm.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 414, Xie, H., Ye, D., Sepich, D., Lin, F., S1pr2/Gα13 signaling regulates the migration of endocardial precursors by controlling endoderm convergence, 228-43, Copyright (2016) with permission from Elsevier. Full text @ Dev. Biol.
