Fig. 6 S2

ID
ZDB-IMAGE-170428-9
Source
Figures for Granneman et al., 2017
Figure Caption

Fig. 6 S2

Developing and adult plin6 mutant fish show no obvious defects.

Wild-type (A–C) and plin6 mutant fish (D–F) are shown. At seven dpf, no discernable defects are observed in plin6 mutants, including the normal development of the melanophore stripe patterning, eye development, swim bladder formation, heart development, and body axis development (all commonly observed developmental defects in fish). Xanthophores are also present (yellow). Some surface xanthophores take up the methylene blue present in the embryo media. Adult caudal fins (C, F) show normal fin morphology in plin6 mutants. A slight reduction of carotenoid (yellow) pigmentation can now be observed in the mutants.
