Fig. 2

ID
ZDB-IMAGE-170424-27
Source
Figures for Zhang et al., 2017
Figure Caption

Fig. 2

Myomaker is not required cell autonomously for myocyte fusion. A: A portion of donor myomakersq36 mutant cells transplanted into wild-type host can undergo myocyte fusion. The image shows a rhodamine-labeled donor mutant cell, which also expresses H2B-GFP in its nuclei, that underwent fusion to form a multinucleated cell with 6 nuclei (indicated by triangles), and a rhodamine-labeled donor mutant cell that did not undergo fusion and remained mononucleated (indicated by an arrow). All nuclei and cell membranes are stained with DAPI and anti-β-catenin antibodies respectively, while H2B-GFP is labeled with anti-GFP staining. The image is a projection of 2 Z-sections. Scale bar=20 µm. B: Some donor wild-type cells are able to fuse with myomakersq36mutant cells when transplanted into the myomakersq36 mutant host. Top panel shows a rhodamine-labeled multinucleated chimeric cell expressing H2B-GFP in all its nuclei (indicated by triangles). The chimeric cell resulted from fusion between rhodamine-labeled donor wild-type cell and host mutant cells that express H2B-GFP in the nuclei. The bottom panel shows a rhodamine-labeled donor wild-type cell that did not undergo fusion and remained mononucleated (indicated by an arrow). Nuclei and cell membranes are stained with DAPI and anti-β-catenin antibodies respectively, while H2B-GFP is labeled with anti-GFP staining. The top and bottom panel images are projections of 5 and 3 Z-sections respectively. Scale bar=20 µm.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 423(1), Zhang, W., Roy, S., Myomaker is required for the fusion of fast-twitch myocytes in the zebrafish embryo, 24-33, Copyright (2017) with permission from Elsevier. Full text @ Dev. Biol.
