Figure Caption
Fig. 5 S1
Presence of medial vessel and blood progenitors is unaffected in hans6 mutants.
(A–F) In situ hybridization depicts expression of etv2 (A, B), tal1 (C, D), and gata1 (E, F) in wild-type (A, C, E) and hans6 mutant (B, D, F) embryos; dorsal views, anterior to the top, of the posterior mesoderm at the 6 somite stage. Expression of all three markers appears unperturbed by loss of hand2 function at this stage. Scale bar represents 100 μm.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Elife
