Figure Caption
Fig. 8 S1
Expression patterns of osr1 and hand2 appear unaffected by loss of each other's function.
(A–D) In situ hybridization depicts expression of osr1 (A, B) and hand2 (C, D) in the posterior mesoderm of wild-type (A, C), hans6 mutant (B), and osr1 MO (D) embryos; dorsal views, anterior to the top, of the posterior portion of the embryo at the 4 somite (A, B) and 6 somite (C, D) stages. (A, B) Loss of hand2 function does not appear to affect osr1 expression. (C, D) Loss of osr1 function does not appear to affect hand2 expression. Scale bar represents 100 µm.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Elife
