Fig. 3

ID
ZDB-IMAGE-161202-35
Source
Figures for Schauerte et al., 1998
Figure Caption

Fig. 3

(A) Nomarski picture showing wild-type and syutq252 mutant embryos at 72 hpf in lateral view. The somites are clearly U-shaped and the horizontal myoseptum is missing in the syu mutant embryo, causing the failure of melanophores to assemble in a lateral stripe. (B) Dark-field picture showing the somites of wild-type and syutbq70 mutant embryos at 72 hpf in lateral view. Striated muscle shows a bright birefringence and somite boundaries show as dark lines. Wildtype somites are V-shaped and separated into a dorsal and a ventral part by the horizontal myoseptum. The somites in the syu mutant embryo are reduced in size, clearly U-shaped and lack a horizontal myoseptum.

Figure Data
