Figure Caption
Fig. 3
Xanthophore pigment is reduced in edison and brie. Day 6 larva, dorsal view of the head region posterior to the eyes, viewed with nomarski optics (A,C,E) and lateral view of ammonia-induced fluorescence in the trunk under UV light epi-illumination (B,D,F). Wild type (A,B) and homozygous mutant larvae of edito255b (C), editc245c (D), and britj226a (E,F). M, melanophores; X and arrow, xanthophores.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
