Figure Caption
Fig. 6
taz mRNA expression in zebrafish embryos. In situ hybridization with antisense taz RNA. (A, B) Expression of taz in the pronephric progenitor field (white arrows in A and B) at the bud stage. (A) Lateral view, anterior is to the left, dorsal is up. (B) Posterodorsal view, anterior is to the left. (C) Expression of taz in somites but not in pronephric progenitor field at the 11-somite stage.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Mechanisms of Development, 138 Pt 3, Zhang, J., Yuan, S., Vasilyev, A., Amin Arnaout, M., The transcriptional coactivator Taz regulates proximodistal patterning of the pronephric tubule in zebrafish, 328-35, Copyright (2015) with permission from Elsevier. Full text @ Mech. Dev.
