Figure Caption
Fig. S5
Knockdown ofcdondoes not affectpatchedorgliexpression. (A)–(E) patched1/2 and gli1 expression following cdon knockdown. (F)–(I) ISH of cdon MO with patched1 in whole mount and 12 µm sections shows no change in patched1 expression. (J) Similarly, qRT-PCR for both patched1/2 and gli1 also shows no change in expression. Statistics were performed with a Students T-test, error bars are standard error of the mean (sem).
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 407(2), Powell, D.R., Williams, J.S., Hernandez-Lagunas, L., Salcedo, E., O'Brien, J.H., Bruk Artinger, K., Cdon promotes neural crest migration by regulating N-cadherin localization, 289-99, Copyright (2015) with permission from Elsevier. Full text @ Dev. Biol.
