Figure Caption

Fig. 2

Retinal cell differentiation is delayed in the rw440 mutant. (A and B) Wild-type (A) and rw440 mutant (B) retinas labeled with rx1 RNA probe (blue) at 1 dpf. (C and D) Wild-type (C) and rw440 mutant (D) retinas labeled with ath5:GFP (green) at 2 dpf. In wild-type retina, ath5:GFP is strongly expressed in the RGCs and weakly expressed in other retinal neurons such as amacrine cells and ONL cells. In the rw440 mutant retina, a weak expression of ath5:GFP is observed in the central retina. (E and F) Wild-type (E) and the rw440 mutant (F) retinas labeled with zn5 antibody (green) at 2 dpf. The zn5 antibody labels RGCs in the wild type. In the rw440 mutant, a small number of cells express zn5 (arrowheads, F). (G and H) Wild-type (G) and rw440 mutant (H) retinas labeled with zn5 antibody (green) and phalloidin (magenta) at 3 dpf. Phalloidin labels the IPL and the OPL, making the ONL evident. In the rw440 mutant retina, zn5-labeled RGCs increase (arrowheads), but there is no OPL. (I and J) Wild-type (I) and rw440 mutant (J) retinas labeled with zpr1 antibody (magenta) at 3 dpf. Nuclei were labeled with Sytox Green (green). The zpr1 antibody labels double cone photoreceptors (PR). In the rw440 mutant retina, there is no zpr1 signal. (K and L) Wild-type (K) and the rw440 mutant (L) retinas labeled with anti-Pax6 antibody (green) at 4 dpf. RGCs and amacrine cells express Pax6. In the rw440 mutant retina, presumptive RGCs and some INL cells express Pax6 (arrows, L). (M and N) Wild-type (M) and the rw440 (N) mutant retinas labeled with zpr1 antibody (magenta) at 4 dpf. In the rw440 mutant retina, some ONL cells express zpr1 (arrowheads, N) in clusters. (O and P) Wild-type (O) and the rw440 mutant (P) retinas labeled with anti-Pax6 antibody (green) at 5 dpf. In the rw440 mutant retina, presumptive RGCs and some ONL cells express Pax6 (arrows, P). (Q and R) Wild-type (Q) and the rw440 mutant (R) retinas labeled with zpr1 antibody (magenta) at 5 dpf. In the rw440 mutant retina, clustered ONL cells express zpr1 (arrowheads, R). RGC, retinal ganglion cell; ONL, outer plexiform layer; PR, photoreceptor.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 394(1), Imai, F., Yoshizawa, A., Matsuzaki, A., Oguri, E., Araragi, M., Nishiwaki, Y., Masai, I., Stem-loop binding protein is required for retinal cell proliferation, neurogenesis, and intraretinal axon pathfinding in zebrafish, 94-109, Copyright (2014) with permission from Elsevier. Full text @ Dev. Biol.
