Fig. 17

ID
ZDB-IMAGE-141007-85
Genes
Source
Figures for England et al., 2014
Figure Caption

Fig. 17 Wild-Type. Prim-10 (27 hpf). Probe synthesis and in situ hybridisation was performed as described in England et al., Identifying Transcription Factors Expressed by Ventral Spinal Cord Interneurons. ZFIN on-line publication, 2014. Primer sequences were: Forward: CGGCAGTCTTCAGTAAGTTTGA. Reverse: AATTAACCCTCACTAAAGGGATGATGCTGTGTCATCACTGCT. PCR product size: 464 bp.

Figure Data
