Fig. 6 K02288 does not inhibit vasculature development.
(Top panels) Brightfield photographs of 48 hours old Tg(fli1a:eGFP) embryos treated with DMSO or chemical inhibitors from 12 hours post fertilization. Embryos were manually dechorionated after bud stage before treatment. (Center panels) Same view under UV light for visualization of eGFP expression in the vasculature. Dorsomorphin and LDN-193189 treatment resulted in intersomitic vessel (ISV) formation defects, consistent with their known inhibition of VEGF signaling. (Lower panels) Higher magnification views of representative embryos and phenotype summary. The most severe phenotypes were observed with dorsomorphin. No effects on ISV formation were observed with K02288 treatment.
