Figure Caption
Fig. S2 Germ layer formation is normal in MZrestsbu29/sbu29 mutants. WISH of germ layer markers in wild-type and rest mutants. All views are dorsal, anterior to the top. (A-F) Domains of mesoderm markers ntl and myod are unaltered in rest mutants. (I,J) Similarly, the endoderm marker axial is also unaltered in rest mutants. (G,H,K,L) Moreover, organizer marker chd and early dorsal neural plate/neural crest marker pax3 expression domains in rest mutants are similar to those of stage-matched wild-type embryos.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
