Figure Caption
Fig. S3 crabp2a and crabp2b morpholinos specifically block translation of co-injected mCherry-tagged mRNA constructs. (A-C) mCherry fluorescence in gastrula stage embryos injected at the one-cell stage with 200 pg crabp2a:mCherry mRNA alone (A; 100%, n=28), co-injected with Crabp2a-MO1 (B; 100%, n=16) or Crabp2a-MO2 (C; 94%, n=18). (D-F) Corresponding DIC images. (G-I) Fluorescence in embryos injected with 200 pg crabp2b:mCherry mRNA alone (G; 100%, n=21), together with Crabp2b-MO1 (H; 86%, n=14), or Crabp2b-MO2 (I; 94%, n=16). (J-L) Corresponding DIC images.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Full text @ Development
