Figure Caption
Fig. S4
Late expression of hadp1 is restricted to the myocardium of the zebrafish heart. (A-H) Serial coronal sections, ventral view, of a 72 hpf zebrafish embyo following whole mount in situ hybridization for hadp1, V=ventricle, A=atrium, y=yolk, BA=bulbous arteriosous, OFT=outflow tract, PA=pharangeal arches.
