Fig. 3

ID
ZDB-IMAGE-110920-44
Source
Figures for Bohnsack et al., 2011
Figure Caption

Fig. 3

PTU alters IGF regulation of craniofacial muscle development.

72 hpf Tg(α-actin::EGFP) embryos that were injected with morpholinos against igf1ra (A–D), igf1rb (E–H), or control (globin; I–L) and were raised in control media (A, B, E, F, I, J) or with 0.003% PTU at 12 hpf (C, D, G, H, K, L). Morpholino knockdown of igf1ra or igf1rb in the roy background (in the absence of PTU; A, B, E, F) did not disrupt craniofacial development as compared to control (I, J). Morpholino knockdown of igf1ra in the presence of 0.003% PTU caused developmental delay only in the presence of 0.003% PTU (C, D compared to K, L). Knockdown of igf1rb inhibited jaw formation and caused mild thickening of extraocular muscles in the presence of 0.003% PTU (G, H), but not in control media (E, F). IR, inferior rectus; IO, inferior oblique; AM, anterior mandibulae.
