Fig. 5

ID
ZDB-IMAGE-100830-5
Antibodies
Source
Figures for Hsu et al., 2010
Figure Caption

Fig. 5 The zs-4 antibody recognizes the extracellular domain of Crb2a. (A-A″) Single confocal z-section of the photoreceptor layer in a 6 d wild-type retina labeled with rabbit panCrb antibodies (A) and zs-4 monoclonal (A′) and the two channels merged (A″). The arrow indicates where anti-panCrb and zs-4 labeling does not appear to fully overlap. (B-C″) Confocal z-projection of a 6 d retina labeled with anti-HA antibody (monoclonal IgG3; red) and zs-4 antibody (blue) and merged with anti-GFP (green). (B-B″) Wild-type retina. (C-C″) Crb2aExtra_TM transgenic retina. Endogenous Crb2a labeling is weak in comparison to Crb2aExtra_TM protein (C″). (D-F′) Confocal z-projection of the photoreceptor layer in a 6 d retina labeled with zs-4 antibody (red), rods express GFP (green). TO-PRO-3 (blue) labeling reveals the position of nuclei in the photoreceptor layer. (D-D′) Wild-type retina. (E-E″) Crb2aExtra_Secr transgenic retina. Single z-section from the white boxed area in E′, showing zs-4 labeling around the inner segment (indicated by yellow bracket and outlined in yellow) of a double-cone, the cell-body is circled in white (E″). (F-F′) Crb2aExtra_Secr transgenic retina where no rods are present. (G-H) Single z-section of the brain ventricular region of a 40 hour postfertilization embryo labeled with zs-4 antibody (red) showing ventricular surface labeling. Cell nuclei are labeled with TO-PRO-3 (blue). (G) Wild-type embryo. (H) ome (crb2a) mutant embryo. The midline (where the ventricles would normally form) is indicated by the white arrow, and eyes indicated by dashed white lines. Scale bars, 5 μm (A-A″′, D-F′) 10 μm (G, H).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.
Open Access.
Full text @ BMC Cell Biol.
