Fig. 3

ID
ZDB-IMAGE-100401-3
Antibodies
Source
Figures for Christie et al., 2010
Figure Caption

Fig. 3 sykHI:zap-70HI morphants resemble vegfa morphants and lack activated ERK. (A) sykHI:zap-70HI Tg(fli1a:EGFP)y1morphants have a complete suppression of ISV sprouting which is phenotypically similar to the ISV stalling observed in high dose vegfa morphants (B). While the artery of 20s wildtype (WT) embryos (arrow, C′) shows activated ERK (arrow, C″) comparable staged sykHI:zap-70HI morphants (D) show a strong downregulation of activated ERK (arrow D′ = artery, D″). The level of downregulation of activated ERK in the artery (arrow, E′) is similar to vegfaHI morphants (E, E″). C′, D′, E′ are enlargements of GFP signal in the boxed region of C, D, E, respectively. C″, D″, E″ are enlargements of the αERK-P immunohistochemistry in the boxed regions of C, D, and E respectively.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 340(1), Christie, T.L., Carter, A., Rollins, E.L., and Childs, S.J., Syk and Zap-70 function redundantly to promote angioblast migration, 22-29, Copyright (2010) with permission from Elsevier. Full text @ Dev. Biol.
