ZFIN Image: Bonkowsky et al., 2008, Fig. S1


Figure Caption

Fig. S1 Loss of lef1 leads to absent foxP2 expression in the tectum, mid-hindbrain boundary, and hindbrain. Whole-mount in situs at 48 hpf; anterior to left, dorsal up, eyes removed. Scale bar = 50 μm. (Conditions: hs:Δtcf- Tg(hsp70l:Δtcf:GFP)^w26, lef1 mo- lef1 morphants, wt- wild type, x8- homozygous Df(LG01)^x8. Abbreviations: hb: hindbrain; mhb: mid-hindbrain boundary; tec: tectum; tel: telencephalon.) (A, B) lef1 morphant (B) lacks expression in tectum and has diminished expression in the hindbrain (arrows), compared to wild-type (A). (C) In Df(LG01)^x8homozygote, expression is absent in the tectum and hindbrain (arrows). (D) In Tg(hsp70l:Δtcf:GFP)^w26embryo, collected four hours after heat shocking, expression is absent from the tectum and hindbrain (arrows). MHB expression is reduced but not absent, perhaps because lef1 induction of foxP2 expression is already sufficiently established by the time of heat-shock.

Figure Data

Expression / Labeling details
