Fig. S3

ID
ZDB-IMAGE-091113-107
Source
Figures for Sanek et al., 2009
Figure Caption

Fig. S3 Apoptosis does not contribute to OS patterning defects observed in Zic2a-depleted embryos. p53MO-injected embryos exhibit normal pax2a expression in the OS (A, 20/20 embryos, n=2). zic2a morphants exhibit strong pax2a expansion into the ventral retina (B, 20/23 embryos, n=2). Embryos co-injected with p53MO and zic2aMO show a similarly strong expansion of pax2a into the adjacent ventral retina (C, 21/21 embryos, n=2). A-C are lateral views, anterior to the left. A′-C′ are ventral views of the same embryos, anterior to the left. All embryos are at prim-5.
