Fig. 7

ID
ZDB-IMAGE-090518-9
Source
Figures for Thisse et al., 1995
Figure Caption

Fig. 7 Expression pattern of snail2 and no tail in wild-type and spadetail (sptb104) mutant embryos at gastrulation. (A–C) Wild-type and (D–F) sibling spadetail embryos at 90% epiboly. (A and D) Dorsoanterior view; (B and E) dorsoposterior view; (C and F) right side views. An asterisk marks the presumptive hatching gland domain and an arrowhead indicates the marginal zone. spadetail embryos have fewer snail2-expressing cells laterally than wild type. snail2-expressing cells in the axis occupy an irregular, loose, and broader domain compared to wild type. The snail2 expression domain is also closer to the margin. This shows that a spadetail embryo is shorter than wild type and that the axial domain of snail2 expression is enlarged at gastrulation. This broadening of axial mesoderm was confirmed by examining the distribution of no tail RNA, a notochord marker (Schulte-Merker et al., 1994) in wild-type (G) and spadetail mutant (H) embryos at 80% epiboly. Anteroposterior (a–p). Scale bar, 25 μm.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 172, Thisse, C., Thisse, B., and Postlethwait, J.H., Expression of snail2, a second member of the zebrafish Snail family, in cephalic mesendoderm and presumptive neural crest of wild-type and spadetail mutant embryos, 86-99, Copyright (1995) with permission from Elsevier. Full text @ Dev. Biol.
