Fig. 1

ID
ZDB-IMAGE-090508-8
Source
Figures for Riley et al., 1997
Figure Caption

Fig. 1 Early development of otoliths in wild-type and mnl embryos. Live embryos were viewed with a 100x objective using DIC optics. (A–C) Wild-type ear at 18.5 h (19 somites). (A) Lateral view of otic vesicle showing positions of anterior otolith and naked posterior tether. The anterior end of the vesicle has expanded more than the posterior end. (B) Close-up of the anterior end of the ear shown in A. The otolith, which appears as a composite of smaller particles, is attached to two distinct tethers. (C) Close-up of the posterior end of the ear shown in A. A single tether is visible, but no otolith is yet detectable. 20 min later (20 somites), the first signs of posterior otolith formation are evident (D). (E) Wild-type ear at 21.5 h (25 somites). Otoliths have increased in size and tethers have lengthened by several micrometers. Inset shows close-up of the anterior otolith and two tethers. (F) Wild-type ear at 24 h (30 somites). Otoliths have continued to grow. Inset shows close-up of anterior otolith and two tethers. No additional hair cell cilia are yet visible. (G) Close-up of mutant ear at 19 h (20 somites). Two tethers are visible but no signs of otolith formation are evident. (H) Mutant ear at 21.5 h (25 somites). Otoliths have not yet formed. Inset shows close-up of two anterior tethers lacking an otolith. (I) Mutant ear at 24 h (30 somites). A large posterior otolith is evident, but no anterior otolith has formed. Inset shows close-up of two anterior tethers lacking an otolith. All images are oriented with anterior to the left and dorsal upward. o, otoliths; arrows, tethers without otoliths. Scale bar, 5 (B, C, D, and G) or 25 μm (A, E, F, H, and I). Insets in E, F, H, and I show 2.6x enlargements of indicated features.

Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 191(2), Riley, B.B., Zhu, C., Janetopoulos, C., and Aufderheide, K.J., A critical period of ear development controlled by distinct populations of ciliated cells in the zebrafish, 191-201, Copyright (1997) with permission from Elsevier. Full text @ Dev. Biol.
