Fig. 5

ID
ZDB-IMAGE-081205-4
Genes
Source
Figures for Blin et al., 2008
Figure Caption

Fig. 5 Compared expression of NR4A2a and PCNA in the zebrafish larval brain. Double staining for NR4A2a transcripts (in situ hybridization, blue staining) and PCNA protein (immunocytochemistry, brown) in the brain at 72 hpf on paraffin sections. All views are cross-sections, dorsal to the top, in order along the antero-posterior axis as indicated on the schematic (bottom panel, see Fig. 6). Black arrows indicate cellular co-expression.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Molecular and cellular neurosciences, 39(4), Blin, M., Norton, W., Bally-Cuif, L., and Vernier, P., NR4A2 controls the differentiation of selective dopaminergic nuclei in the zebrafish brain, 592-604, Copyright (2008) with permission from Elsevier. Full text @ Mol. Cell Neurosci.
