ZFIN Image: Chung et al., 2008, Fig. S1


Figure Caption

Fig. S1 Expression Pattern of bmp2a, 2b, 4 and 7
(A-B) Dorsal views of bmp4 (A) and bmp7 (B) expression at 21 and 24 hpf, respectively. (A) bmp4 is mainly expressed in the cardiac mesoderm (arrow). (B) bmp7 is expressed in the head region and otic vesicles (arrowheads).
(C and D) Dorsal views of bmp2a (C) and bmp2b (D) expression at 24 hpf. bmp2a and bmp2b are both expressed in the lateral plate mesoderm (dotted square) and fin folds (arrows) at this stage. (D) bmp2b is also expressed in the otic vesicles (arrowheads).
(E and F) Lateral (E) and dorsal (F) views of bmp2b expression at 75% epiboly (E) and the 5-somite stage (F). (E) bmp2b is expressed ventrally as well as in the dorsal organizer at 75% epiboly. (F) At the 5-somite stage, bmp2b is mainly expressed in the epidermis.

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Cell, 15(5), Chung, W.S., Shin, C.H., and Stainier, D.Y., Bmp2 signaling regulates the hepatic versus pancreatic fate decision, 738-748, Copyright (2008) with permission from Elsevier. Full text @ Dev. Cell
