Fig. 2

ID
ZDB-IMAGE-080829-11
Genes
Antibodies
Source
Figures for Punnamoottil et al., 2008
Figure Caption

Fig. 2 YFP expression in 1-dpf embryos of hoxa4a, hoxb4a, and hoxd4a enhancer detection lines as detected by immunohistochemistry. A-C: YFP expression pattern in the hindbrain and spinal cord of the transgenic lines CLGY409, CLGY838 and CLGY846. A′: Hoxa4a-YFP expression in elongated neuroepithelial cells in r8. The level of section is indicated in A. B′, B″: Transverse sections through the hindbrain of CLGY 838 show hoxb4a-YFP expression in elongated neuronal precursor cells on the level of r7 (B′) and r8, which also shows a neuron with a ventromedial projection (B″, black arrow). The levels of sections are indicated in B. C′: Many neuroepithelial cells were YFP positive in r7 of the hoxd4a enhancer detection embryos. The level of section is indicated in C. C″: Section through r7 of hoxd4a embryos at 1.5 dpf, showing YFP-positive postmitotic neurons, with young immature neurons sending out small primary projections (black arrows).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Dev. Dyn.
