Figure Caption
Fig. 2 shh in the MFP can induce LFP cells. Dorsal views (anterior is left) of shh (A, C, E, G) and fkd4 (B, D, F, H) expression in wild-type (A, B), flhtk241 (C, D), momth211 (E, F), and ntltc41 (G, H) embryos in the pharyngula period. Cells around shh-expressing MFP cells in flh and mom embryos express fkd4 in the ventral neural tube (D, F). In ntl embryos cells adjacent to the broadened MFP transcribe fkd4, suggesting that in the absence of a notochord shh expression in the MFP can induce LFP development.
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 219(2), Odenthal, J., van Eeden, F.J., Haffter, P., Ingham, P.W., and Nüsslein-Volhard, C., Two distinct cell populations in the floor plate of the zebrafish are induced by different pathways, 350-363, Copyright (2000) with permission from Elsevier. Full text @ Dev. Biol.
