Fig. 2

ID
ZDB-IMAGE-080108-2
Genes
Source
Figures for Murayama et al., 2006
Figure Caption

Fig. 2 c-myb Expression Reveals the Successive Sites of Larval and Definitive Hematopoiesis Whole-mount in situ hybridization at successive developmental stages. (A) 26 hpf, short after blood circulation onset; position of somite 6 is indicated. (B) Close-up on the area boxed in (A). (C) 5 dpf. (D and E) Ventral views (rostral up) of c-myb+ cells around the pronephric glomerulus (g) at (D) 4 dpf and (E) 5 dpf. (F) 7 dpf. (G) Ventral view (rostral up) of the pronephric region at 7 dpf. (H and I) Higher magnification lateral views (rostral left) of c-myb+ cells in (H) the trunk and (I) the tail, occurring around c-myb- cell clusters (purple arrows). e, primitive erythrocytes; blue arrows, thymus; red arrows, pronephros; green arrows, branchial arches; arrowheads, c-myb+ patches along the PCV. Scale bars represent 200 μm in (A), (C), and (F); 50 μm otherwise.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Immunity, 25(6), Murayama, E., Kissa, K., Zapata, A., Mordelet, E., Briolat, V., Lin, H.F., Handin, R.I., and Herbomel, P., Tracing Hematopoietic Precursor Migration to Successive Hematopoietic Organs during Zebrafish Development, 963-975, Copyright (2006) with permission from Elsevier. Full text @ Immunity
