Fig. 7

ID
ZDB-IMAGE-071223-6
Source
Figures for Yabe et al., 2007
Figure Caption

Fig. 7 One-cycle cell division delay in embryos from mutant cea fathers. Live embryos at the indicated time points. (A–F) are side views, (B′, D′) are animal views of the same embryos shown in panels B, D. A fraction of paternally mutant cea embryos show a one-cycle delay in cell division (panel C, compare to panel A), but subsequently resume normal cleavage (D, D′). At 5 days p.f., embryos that undergo a one-cycle delay in cell division (F) exhibit heart edema (asterisk) and lack swim-bladder inflation (arrow). (G, H) Metaphase spreads from 24-h embryos. Wild-type embryos contain a normal complement of 50 chromosomes (G), while paternally mutant cea embryos that experience a one-cell cycle delay in the first cell division contain a duplicated number of chromosomes (H).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 312(1), Yabe, T., Ge, X., and Pelegri, F., The zebrafish maternal-effect gene cellular atoll encodes the centriolar component sas-6 and defects in its paternal function promote whole genome duplication, 44-60, Copyright (2007) with permission from Elsevier. Full text @ Dev. Biol.
