Fig. 7

ID
ZDB-IMAGE-071005-34
Genes
Source
Figures for Kaji et al., 2004
Figure Caption

Fig. 7 Expression of the upstream gene, neurogenin1, for HuC, tlx3a, and neuroD marking RB neurons and neurons in the trigeminal placodes, in embryos injected with dlx3b-MO and dlx4b-MO at 3-somite stage. (A and C) Wild-type embryos. (B and D) 20 ng ATG-dlx3b-MO/20 ng ATG-dlx4b-MO-injected embryos. (A and B) The expression of neurogenin1 in RB neuron precursors (rb) is normal in MO-injected embryos. Dorsal views. (C and D) The expression of neurogenin1 in the precursors of neurons in the trigeminal placodes (tg) is absent in MOs-injected embryos (D). Anterior views. mn, primary motor neuron precursors; in, primary interneuron precursors; mi, anterior medial hindbrain interneuron precursors; li, anterior lateral hindbrain interneuron precursors.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 276(2), Kaji, T., and Artinger, K.B., dlx3b and dlx4b function in the development of Rohon-Beard sensory neurons and trigeminal placode in the zebrafish neurula, 523-540, Copyright (2004) with permission from Elsevier. Full text @ Dev. Biol.
