Fig. 8

ID
ZDB-IMAGE-070925-96
Genes
Source
Figures for Gulati-Leekha et al., 2006
Figure Caption

Fig. 8  Motoxonal branching and terminal innervation is impaired in the dhv spinal cord. Mutants become discernible at 2 dpf displaying progressive paralysis and other dysmorphologies (bright-field images showing lateral view of embryos (A) accompanied by fluorescent ventral projections (arrows; B) from the spinal cord (sc, lateral view, anterior towards left) into the ventral myotome (vm). GFP immunostaining of transverse spinal cord sections further highlights the GFP-positive spinal nerves (arrowheads, C). znp-1 immunostaining of caudal (D, E) and rostral (F, G) myotomal segments at 57 hpf shows lack of secondary and tertiary (2′,3′; D) motoaxonal branches in dhv. Note the stunted lateral projections (arrows; panels E and G) and swollen varicosities (arrowheads; panels E and G). Intense staining of spinal cord precludes examination of dorsal myotome. Motor axonal pathfinding is indistinguishable between mutant and wild-type spinal cords at 32 hpf (representative znp-1 immunostaining; H). Mutation in dhruva forestalls down-regulation of DM-GRASP expression, which marks secondary motor neurons (smn) and corresponding fasciculated axonal segments (zn-5 immunostaining at 57 hpf, representative mid-trunk spinal cord segments; panels I and J). Scale bars: 250 μm in panel A, 50 μm in panel B, 25 μm in panels C, D–G, and H–J.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 296(1), Gulati-Leekha, A., and Goldman, D., A reporter-assisted mutagenesis screen using α1-tubulin-GFP transgenic zebrafish uncovers missteps during neuronal development and axonogenesis, 29-47, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
