Fig. 6

ID
ZDB-IMAGE-070613-93
Genes
Source
Figures for Drerup et al., 2007
Figure Caption

Fig. 6 Expression of ndel1b during somite and brain development in the zebrafish. Lateral (A–C and D–I) and dorsal (A2–C2) views of zebrafish after ndel1b specific in situ hybridization with anterior to the left. Widespread ventral expression in the somitic mesoderm at 14 hpf persists and expands dorsally through 19.5 hpf (A–C and A2–C2). Expression then gradually becomes restricted in an anterior to posterior gradient during the maturation of the somites until ndel1b is only expressed in the tip of the tail at 24 hpf (D). At 48 hpf (F) ndel1b is again expressed in the ventral area of the trunk and tail but this expression is gone by 72 hpf (G). Instead, from 72 to 120 hpf expression shifts to the developing brain (G–I). Hybridization with the ndel1b sense probe shows no specific staining pattern. Representative 24 hpf embryo after sense probe hybridization in (E).

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Gene expression patterns : GEP, 7(6), Drerup, C.M., Ahlgren, S.C., and Morris, J.A., Expression profiles of ndel1a and ndel1b, two orthologs of the NudE-Like gene, in the zebrafish, 672-679, Copyright (2007) with permission from Elsevier. Full text @ Gene Expr. Patterns
