Fig. 4

ID
ZDB-IMAGE-060710-4
Genes
Source
Figures for Shaw et al., 2006
Figure Caption

Fig. 4 Disruption of somitic markers in y56 mutants. A-H: Whole-mount in situ hybridization of the trunk region of wild-type (A,C,E,G) and y56 mutant (B,D,F,H) animals at 16.5 hours postfertilization (hpf; A,B) and 19-21 hpf (C-H) using probes for efnb2a (A,B), sema3a1 (C,D), sema3a2 (E,F), and her1 (G,H). Somitic markers show a more disorganized pattern of expression in y56 mutants. Anterior is to the left and dorsal is up in all panels.

Figure Data
