Fig. 5

ID
ZDB-IMAGE-060202-4
Genes
Source
Figures for Pietsch et al., 2006
Figure Caption

Fig. 5 Developmental expression pattern of trap100. (A-F) Whole-mount in situ hybridized embryos hybridized with a trap100 antisense probe at the indicated developmental stages. (A-D,F) Lateral views; (E) Dorsal view of 24 hpf embryo. Asterisks in D-F indicates the otic vesicle. Arrows in E indicate fin buds. Arrowhead in F indicates increased expression of trap100 in the posterior mesencephalon. Arrows in F indicate intestinal mesendodermal expression of trap100. (G) A transverse section taken through 48 hpf embryo at the level of somite 4 showing expression through the intestinal mesendoderm. Arrows indicate intestinal mesendodermal expression of trap100. (H) A transverse section taken trough the gut tube at 60 hpf after double in situ hybridization with a trap100 fluorescein antisense probe (red) and a phox2b digoxigenin antisense probe (purple) showing intestinal epithelia expression of trap100. (I) Same section as in H showing trap100 expression using fluorescence in the intestinal epithelia cells. Arrows and asterisks in H,I indicate intestinal mesendodermal expression of trap100and phox2b-positive ENS precursors, respectively. (J,K) Whole-mount in situ hybridized embryos hybridized with a trap100 antisense probe at 72 hpf. (J) Lateral view; (K) dorsal view. Arrowheads in J indicate pharyngeal arch mesendodermal expression. Arrowhead in K indicates ventral diencephalon cells expressing neurons expressing trap100. In all whole mounts (A-F,J,K), anterior is towards the left; (F,K,J) yolk has been removed.

Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
