Fig. 5

ID
ZDB-IMAGE-060130-3634
Genes
Source
Figures for Schulte-Merker et al., 1994
Figure Caption

Fig. 5 Expression of ntl RNA in ntl mutant embryos. (A-D) Whole-mount in situ hybridizations detecting ntl mRNA. (A) Mutant ntlb160 embryos (two embryos on the left) at the embryonic shield stage exhibit reduced levels of ntl transcript if compared to sibling embryos (two embryos on the right). Mutant embryos were identified by their lack of Ntl protein after antibody stainings. (B) Wild-type sibling of embryo shown in (C) at 100% epiboly. There is strong expression of ntl RNA in the axial mesoderm and the germ ring. (C) Mutant ntlb195 embryo at 95% epiboly. Transcript levels are high in the germ ring, but hardly detectable in the presumptive notochord (arrowhead). Note the staining of dorsal marginal cells (see text for details). (D) Mutant ntlb160 embryo at tailbud stage (10h), demonstrating that mutant embryos of both alleles behave indistinguishably with respect to ntl mRNA expression in cells of the presumprive notochord (arrowhead).

Figure Data
