Figure 4

Constitutive homozygous snx14 mutations do not impact zebrafish morphology at 4dpf but do increase FAs from neutral lipid and phospholipids. (A) Illustration and demonstration of zebrafish eye (E) width and head (H) width measurements of maternal zygotic (MZ) snx14^Mut/Mut fish derived from snx14^Mut/Mut female and snx14^WT/Mut male pairs. (B) Maximum projected confocal images of heads (dorsal view) from 4dpf zebrafish embryos either snx14^WT/Mut or MZ-snx14^Mut/Mut. Staining employed immunohistochemistry against acetylated tubulin (green), marking axon tracts and SV2 (magenta) marking neuropil areas. (C–E) Relative FA levels from whole body lysates of 4dpf zebrafish. Neutral lipid fraction-derived FA 16:0 (C), FA 18:1(n9) (D) and FA 20:4(n6) (E) were elevated in snx14^Mut/Mut zebrafish compared to both snx14^WT/WT and snx14^WT/Mut zebrafish. (F–H) Phospholipid fraction-derived FA 16:0 (F), FA 18:1(n9) (G) and FA 20:4(n6) (H) were elevated in both snx14^Mut/Mut and snx14^WT/Mut zebrafish compared to snx14^WT/WT zebrafish. N = 3 (Pool of 6 zebrafish in each lysate), circles = individual lysate values, bars = mean, error bars = SD, **(p ≤ 0.01), n.s. (p ≥ 0.05), one-way ANOVA.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	snx14^{sa18413/sa18413}
Observed In:	central nervous system whole organism fatty acid 16:0 whole organism fatty acid 18:1 whole organism fatty acid 20:4 whole organism glycerophospholipid whole organism locomotory behavior
Stage:	Day 4

Phenotype Detail
